External Mini SAS HD 1x2, 4X with ReDriver to PCIe x8 Golden Finger

$74.75
Availability: In stock
Only 6 left
Part #
MS-2012-X8

Installing the 4X with ReDriver to PCIe x8 Golden Finger is a perfect way to easily enable the External Mini SAS HD 1x2(4X) to the PCIe x8 GF Gen 3 convert. The model also has a built-in ReDriver for extending PCIe 3.0 and 8GT/s differential pair signals.

Installing the 4X with ReDriver to PCIe x8 Golden Finger is a perfect way to easily enable the External Mini SAS HD 1x2(4X) to the PCIe x8 GF Gen 3 convert. The model also has a built-in ReDriver for extending PCIe 3.0 and 8GT/s differential pair signals. It gives the better pair signals eight lanes data link widths and assures saving time. These extensively provide programmable linear equalization with better output swing and gain. Built-in PCIe 100MHz Clock assures enabling better buffer for driving the longer trace length. These are also enabled with longer cable lengths for high-end connectivity. These have the unique Built-in PCIe SMCLK plug along the socket family. It is an efficient option for making data transmission easier using this socket.

More Information
Part # MS-2012-X8
Bar Code (UPC) 611851926311
Specifications

External Mini SAS HD 1x2, 4X with ReDriver to PCIe x8 Golden Finger

Features :

• External Mini SAS HD 1x2(4X) to PCIe x8 GF Gen 3 convert

• Built-in SFF-8644 1x2(4X), 30 microinches connector

• Built-in ReDriver to extend PCIe 3.0, 8GT/s differential pair signals 8 lanes data link widths and provides programmable linear equalization, output swing and gain

• Built-in PCIe 100MHz Clock buffer to drive longer trace length and longer cable length

• Built-in PCIe SMCLK, SMDAT bidirectional buffer repeater

• Built-in PERST# Bus Buffer Gate to be used over longer trace length and over longer cable length

• Built-in WAKE# Bus Buffer Gate to be used over longer trace length and over longer cable length

• Built-in CLKREQ# Bus Buffer Gate to be used over longer trace length and over longer cable length.

• D1 Green LED on indicates AIC ready

Specifications :

• PCI Express Base Specification Rev 3.0

• PCIe CEM Rev3.0

• PCI_Express_External_Cabling_R3.0a_06042020_NCB

Micro SATA Cables PN # MS-2012-X8
