U.2 SFF-8639 to M.2 PCIe I/F with 2.5 Inch 9.5mm Case

Rating:
99 % of 100
$22.75
Availability: In stock
Only 22 left
Part #
CASE-994-U2

U.2 SFF-8639 to M.2 PCIe I/F with 2.5 Inch 9.5mm Case‌

The U. 2 SFF - 8639 to M.2 PCIe I / F with 2.5 inches 9.5mm Case adapter and the cable have been tested together in use as RAID0 with two Samsung 950 Pro 512 MB SSDs to better use on an Asus Maximus Hero Alpha a Pro SSD. m 2 to u 2 adapter has different features such as LED ON indicating M.2/PCI-e 4 Lane device power OK, Built M.2 NGFF M-Key receptacle connector, 4 Layer PCB Designed, built-in SFF-8639 Plug connector, LED 3 shows active status, and the case is a 9.5mm 2.5-inch Aluminum housing. u2 to m2 adapter specifications include in-rush current suppression, NVM Express 1.0, PWM synchronous buck converter Power IC, 3.3V, 4A Maximum output current, short circuit protection, thermal shutdown protection, PCI Express Base Specifications Rev 3.0, etc.


Micro SATA Cables PN # CASE-994-U2

More Information
Part # CASE-994-U2
Bar Code (UPC) 673681049141
Specifications

The U. 2 SFF - 8639 to M.2 PCIe I / F with 2.5 inch 9.5mm Case adapter and cable have been tested together in use as RAID0 with two Samsung 950 Pro 512 MB SSD's to use on a Asus Maximus Hero Alpha a Pro SSD. Features:

  • 4 Layer PCB Designed
  • Built in SFF-8639 Plug connector
  • Built in M.2 NGFF M-Key receptacle connector
  • LED ON indicates M.2/PCI-e 4 Lane device power OK
  • LED 3 indicates active status
  • Case is a 9.5mm 2.5 inch Aluminum housing

Specifications:

  • PCI Express Base Specifications Rev 3.0
  • SFF-8639 Enterprise SSD Form Factor Version 1.0a
  • PCI Express Card Electro-Mechanical (CEM) Specification REV 2.0
  • PCI Express M.2 Spec Revision 0.7, Version 1.0
  • NVM Express 1.0
  • PWM synchronous buck converter Power IC
  • 3.3V, 4A Maximum output current
  • Short circuit protection
  • In-rush current suppression
  • Thermal shut down protection
  • ESD HBM (Human Body Mode) 2KV
  • ESD CDM(Charged Device Mode)/ 500V

Support M.2 M-Key Form Factor

  • Type 2280-D2-B-M : 80mm(L) X 22mm(W)
  • Type 2260-D2-B-M : 60mm(L) X 22mm(W)
  • Type 2242-D2-B-M : 42mm(L) X 22mm(W)
  • Type 2230-D2-B-M : 30mm(L) X 22mm(W)

Operating System Support :

  • Windows 7 64 bit
  • Windows 8 64 bit
  • Windows 8.1 64 bit
  • UEFI 2.3.1 or later

Micro SATA Cables PN # CASE-994-U2
