U.2 Plus SATA 7 Pin to 2,5 Inch U.2 Plus M.2 SSD 3.5 Inch Caddy

$32.75
Availability: Out of stock
Part #
U2-1412-CAD

U.2 Plus SATA 7 Pin to 2,5 Inch U.2 Plus M.2 SSD 3.5 Inch Caddy

Features

  • Build in U.2(SFF-8639) Female connector
  • Supports U.2 SMB_CLK
  • Supports U.2 SMB_DATA
  • Supports U.2 Daul port design
  • Supports SAS Primary port design
  • Support 2.5” U.2 NVMe SSD, M.2 B-key
  • D1 Green LED on indicates M.2 SSD power ready
  • D2 Green LED on indicates U.2 SSD power ready
  • D4 RED LED Blinking indicates U.2 SSD active status
  • D5 RED LED Blinking indicates M.2 SSD active status U.2 & SATA 7-pin to 2.5" U.2 SSD & M.2 SATA SSD

Specifications

  • Compliant with NVM Express 1.0a
  • Support PCI Express Base Specification Rev 3.0
  • Support SSD_Form_Factor_Version1_a
  • Compliant with SFF-8639 Specification Rev 2.0
  • Compliant with SFF-8323 Rev1.6 For 3.5" Form Factor Drive with Serial Attached Connector
  • Compliant with SerialATA_Revision_3_2_Gold

M.2 SSD / M.3 SSD Form Factor Support

  • Type 2242-D2-B-M: 42mm(L) x 22mm(W)
  • Type 2260-D2-B-M: 60mm(L) x 22mm(W)
  • Type 2280-D2-B-M: 80mm(L) x 22mm(W)
  • Type 22110-D2-B-M: 110mm(L) x 22mm(W)
  • Type 305110: 110mm(L) x 30.5mm(W) HD)

NOTE: SSD's shown in pictures are for illustration only and are not included.

Micro SATA Cables PN # U2-1412-CAD

More Information
Part # U2-1412-CAD
Bar Code (UPC) 646791002559
Specifications

Features

  • Build in U.2(SFF-8639) Female connector
  • Supports U.2 SMB_CLK
  • Supports U.2 SMB_DATA
  • Supports U.2 Daul port design
  • Supports SAS Primary port design
  • Support 2.5” U.2 NVMe SSD, M.2 B-key
  • D1 Green LED on indicates M.2 SSD power ready
  • D2 Green LED on indicates U.2 SSD power ready
  • D4 RED LED Blinking indicates U.2 SSD active status
  • D5 RED LED Blinking indicates M.2 SSD active status U.2 & SATA 7-pin to 2.5" U.2 SSD & M.2 SATA SSD

Specifications

  • Compliant with NVM Express 1.0a
  • Support PCI Express Base Specification Rev 3.0
  • Support SSD_Form_Factor_Version1_a
  • Compliant with SFF-8639 Specification Rev 2.0
  • Compliant with SFF-8323 Rev1.6 For 3.5" Form Factor Drive with Serial Attached Connector
  • Compliant with SerialATA_Revision_3_2_Gold

M.2 SSD / M.3 SSD Form Factor Support

  • Type 2242-D2-B-M: 42mm(L) x 22mm(W)
  • Type 2260-D2-B-M: 60mm(L) x 22mm(W)
  • Type 2280-D2-B-M: 80mm(L) x 22mm(W)
  • Type 22110-D2-B-M: 110mm(L) x 22mm(W)
  • Type 305110: 110mm(L) x 30.5mm(W) HD)

NOTE: SSD's shown in pictures are for illustration only and are not included.

Micro SATA Cables PN # U2-1412-CAD
