SATA III Adapter for mSATA SSD with PCI-e Full Bracket

$14.75
Availability: In stock
Only 27 left
Part #
MSATA-SATA3-BRKT

This unit is a SATA III to mSATA adapter, providing one 7+15pin SATA connector on the host connection and one Mini PCI-e 52-pin connector on the SSD storage devices connections.

SATA III Adapter for mSATA SSD with PCI-e Full Bracket provides one Mini PCI-e 52-pin connector on SSD storage and one 7+15pin SATA connector on host connection. It operates well with multiple operating system. It boot the OS directly without any need of additional drivers and doesn't affect the SSD speed.

The adapter supports hot-plugging, which means that the SSD can be inserted or removed without having to power down the computer.

It is a cost-effective solution for upgrading an older desktop computer with a high-speed SSD, without having to replace the entire system.

It is equipped with an LED indicator that shows the status of the adapter and the connected SSD.

Micro SATA Cables PN # MSATA-SATA3-BRKT

More Information
Part # MSATA-SATA3-BRKT
Bar Code (UPC) 794504721553
Specifications

This unit is a SATA III to mSATA adapter, providing one 7+15pin SATA connector on the host connection and one Mini PCI-e 52-pin connector on the SSD storage devices connections.

When assembled, it can operate in a variety of operating systems. Such as DOS, Windows 95, 98, XP, 2000, Vista, Win 7, Linux, Unix, and so on. AD963FB/C9 adapter allows the installation of an mSATA SSD as system disk, boot the operating system directly, without having to install any drivers, but does not affect the execution speed of the SSD storage devices.

Specifications
  • Fully compliant with SATA revision 3.0
  • PCI Express Mini Card Electromechanical Specification 1.2
  • PWM Power IC / 1.4MHz 5.5V synchronous buck converter
  • mSATA input voltage: 3.3V ±5%, input current: 3A
  • Data transfer rate: 6Gb/s bandwidth
  • Operating temperature – Commercial (0°C to +70°C)

Supports the following form factor mSATA SSD

  • Full size: 50.95 mm (L) x 30mm (W)
  • Half size: 26.8 mm (L) x 30 mm (W)

Supported Storage Devices:

  • Sandisk U100 Series mSATA &compatible Storage
  • Samsung PM830 Series mSATA & compatible Storagee
  • Micron RealSSD C400, C400v mSATA, Crucial mSATA & compatible storage

Micro SATA Cables PN # MSATA-SATA3-BRKT
