PCIe GEN 3 X16 to Mini SAS HD 8X Dual Port Adapter

$54.75
Availability: In stock
Only 1 left
Part #
PCIE-1652-MS

PCIe X16 to Mini SAS HD 8X Dual Port Adapter

Unit can be used with our Micro SATA Cables Part# MIC72-9901

Mini SAS HD 8i Lane X2 to Mini SAS HD 8i Lane X2 Cable

Unit can be used with our Micro SATA Cables Part # M3-1574

‌Mini SAS HD to M.2 / M.3 SSD X2 Drive Tray

The PCIe GEN 3 X16 to Mini SAS HD 8X Dual Port Adapter is a hardware device that allows for the conversion of a PCIe x16 slot on a computer's motherboard into two Mini SAS HD (SFF-8644) ports. These ports support SAS (Serial Attached SCSI) and SATA (Serial ATA) storage devices, including hard disk drives, solid-state drives, and tape drives.

This adapter supports PCIe 3.0, which provides up to 8 GT/s (gigatransfers per second) per lane of data transfer rate, resulting in a maximum bandwidth of 128 GB/s for the x16 slot. The Mini SAS HD ports support data transfer rates of up to 12 Gb/s per lane, allowing for a total bandwidth of up to 192 Gb/s per port.

The adapter has a low-profile design, making it compatible with most computer cases and motherboards. It requires a 6-pin PCIe power connector to provide power to the adapter and the connected storage devices.

The adapter is designed for use in high-performance computing and storage applications, such as data centers and server environments, where large amounts of data need to be transferred quickly and reliably. It is also suitable for use in desktop workstations that require high-speed storage connectivity.

Micro SATA Cables Part# PCIE-1652-MS

More Information
Part # PCIE-1652-MS
Bar Code (UPC) 646791004294
Specifications

‌PCIe X16 to Mini SAS HD 8X Dual Port Adapter

Features :

  • PCIe Gen3 16-lane to Mini SAS HD(SFF-8643) 8x quad-port Adapter can be bifurcated in quad x4(need CPU and BIOS both support) and x4 data link width configurations.
  • PCIe Gen3 16-lane to Mini SAS HD(SFF-8643) 8x quad-port Adapter features four internal NVMe (SFF-8643) for high-performace storage connectivity.
  • Build in Mini SAS HD(SFF-8643) 8x connector 2 sets, pin-out defined by SFF-9402.
  • Four internal lanes per Mini SAS HD port, 3.2Gb/s per port.
  • Supports four physical NVMe devices ※ Supports SFF-9402 clock pin out.
  • Supports Intel define Mini SAS HD(SFF-8643) clock pin out.
  • Supports SFF-9402 perst# pin out.
  • Supports Intel Define Mini SAS HD(SFF-8643) perst# pin out.
  • Enables the system clock signal to be used over longer trace lengths and over a cable
  • Enables the system perst# signal to be used over longer trace lengths and over a cable
Specifications :
  • Compliant with NVM Express 1.2a
  • Support PCI Express Base Specification Rev 3.1
  • Support SSD_Form_Factor_Version1_a
  • Compliant with SFF-8643 Specification Version 3.5
Operating Systems :
  • Vmware
  • Linux
  • Windows 8 &8.1
  • Windows 10
  • UEFI 2.3.1 or later
NOTES :
  • The Mainboard with CPU and BIOS needs to support bifurcation to eusure PCIe x16 link width to bifurcate two x8 link width for NVMe SSD.
  • The unit is for NVMe signals only.  Not to be used in SAS or SATA signals.

Unit can be used with our Micro SATA Cables Part# MIC72-9901

Mini SAS HD 8i Lane X2 to Mini SAS HD 8i Lane X2 Cable

Unit can be used with our Micro SATA Cables Part#M3-1574

Mini SAS HD to M.2 / M.3 SSD X2 Drive Tray

Micro SATA Cables Part# PCIE-1652-MS
