Mini SAS HD PCIe Gen3 to U.2 SSD Adapter with 3.5 Inch Enclosure

$46.75
Availability: In stock
Only 1 left
Part #
MS-1909-U2

Transform your system with the Mini SAS HD PCIe Gen3 to U.2 SSD Adapter in a compact 3.5-inch enclosure. This adapter offers seamless integration, enhancing storage capabilities for high-performance applications.

Experience unparalleled versatility and efficiency with the Mini SAS HD PCIe Gen3 to U.2 SSD Adapter featuring a compact 3.5-inch enclosure. This adapter is meticulously crafted to facilitate seamless conversion from U.2 (SFF-8639) to SFF-8643 MINI SAS HD, catering to diverse storage needs. It innovatively transforms the 2.5-inch HDD form factor to a robust 3.5-inch HDD form factor, ensuring compatibility across modern computing systems.

More Information
Part # MS-1909-U2
Bar Code (UPC) 611851925703
Specifications

Mini SAS HD PCIe Gen3 to U.2 SSD Adapter with 3.5 Inch Enclosure

Features :

  • U.2(SFF-8639) to SFF-8643 MINI SAS HD convert
  • 2.5” H.D.D. form factor to 3.5” H.D.D form factor convert
  • Build in SATA 15 pin power connector
  • Build in SFF-8639 connector, pin-out defined by SFF-9402Rev1.0
  • Build in SFF-8643 connector, pin-out defined by SFF-9402Rev1.0
  • Built-in 12V input with 400W TVS(Transient Voltage Suppressor ESD protection
  • Built-in 12V Hot Plug Power with eFuse protection for U.2 SSD

 - Programmable Current Limit: 6.5A

 - Programmable Inrush Current Slew Rate

 - Thermal shutdown protection and fault alert

  • Built-in 12V output with 30-V, N channel NexFET power MOSFET, 32 m Ohm
  • Built-in 12V output with SCHOTTKY BARRIER Power Rectifier
  • Built-in 3.3Vaux load switch power protection
  • Built-in PCIe 100MHz clock mux
  • LED 2 Red LED on indicates SSD active status
  • LED 1 Green LED Blinking indicates 12V power ready
  • LED 3 Green LED Blinking indicates 3.3VAUX power ready
Specifications :
  • Compliant with NVM Express 1.0a
  • Support PCI Express Base Specification Rev 3.0
  • Support SSD_Form_Factor_Version1_a
  • Compliant with SFF-8639 Specification Rev 2.0
  • Compliant with SFF-8643 Specification Rev 3.5
Apllications :
  • SFF-8643 to SFF-8643 Cable for SFF-8643(mini SAS HD) Host by Intel defined PCIe REFCLK
  • SFF-8654 to SFF-8643 Cable for SFF-8654(SlimsSAS) Host by SFF-9402 defined PCIe REFCLK
  • SFF-8611 to SFF-8643 Cable for SFF-8612(OCulink) Host by SFF-9402 defined PCIe REFCLK
  • SFF-8643 to SFF-8643 Cable for SFF-8643(mini SAS HD) Host by SFF-9402 defined PCIe REFCLK
Micro SATA Cables PN # MS-1909-U2
