M.2 x 2 to SATA III Dual Port Adapter with 3.5 Inch Metal Frame

Part #M2-2PRT-MFR
$14.75

The M.2 x 2 to SATA III Dual Port Adapter with 3.5 Inch Metal Frame is a M.2 (NGFF) to SATA III Module that supports SATA Reversion 3.2 and is compliant with PCI Express M.2 Spec. Version 1.0.

More Information

Part # M2-2PRT-MFR
Bar Code (UPC) 643131530253
Specifications

Specifications

  • M.2 (NGFF) to SATA III Module
  • Support SATA Reversion 3.2
  • Compliant with PCI Express M.2 Spec. Version 1.0
  • PWM synchronous buck converter Power IC
  • 3A maximum output current
  • Short circuit protection
  • In-rush current suppression
  • Thermal shutdown protection
  • ESD HBM (Human Body Mode)/2KV
  • Supports the following form factor M.2(NGFF) SSD:
    • Type 2230-D2-B-M: 30mm(L) x 22mm(W)
    • Type 2242-D2-B-M: 42mm(L) x 22mm(W)
    • Type 2260-D2-B-M: 60mm(L) x 22mm(W)
    • Type 2280-D2-B-M: 80mm(L) x 22mm(W)

Supported Storage Device

  • Compatible with Intel 530 Series M.2 SSD & compatible Storage
  • Compatible withSanDisk X110 M.2 SSD & compatible Storage
  • Compatible withMicron M500 Series M.2 SSD & compatible Storage

Micro SATA Cables PN # M2-2PRT-MFR
