Gen-Z 1C (EDSFF) PCIe Gen 4 16GT/s to M.2 NVMe SSD PCIe GEN 4

Gen-Z 1C (EDSFF) PCIe Gen 4 16GT/s to M.2 NVMe SSD PCIe GEN 4

Features :

※ 4 Lanes of PCIe designated

※ 4-layer PCB designed

※ M.2 NVMe to Gen-Z 1C(EDSF) convert

※ Built-in Gen-Z 1C connector, pin-out defined by SFF-9402 Rev1.3

※ PWM synchronous buck converter Power for M.2 NVMe SSD

◆ 4A maximum output current

◆ Short circuit protection

◆ n-rush current suppression

◆ Thermal shutdown protection

◆ ESD HBM (Human Body Mode)/2KV

※ Built-in power Load Switch with controlled turn on, can support a maximun continuous current of 4A

※ Supports CLKREQ#

※ Supports M.2 /1.8V to Gen-Z 1C/3.3V SMB_CLK, SMBDATA Level Shift

※ Supports M.2 /1.8V to Gen-Z 1C/3.3V SMB_CLK, SMB_DATA isolated, repeater

※ Built-in SMBUS EEPROM 64KB

※ LED1 RED LED Blinking indicates M.2 active status

※ LED 2 Green LED on indicates M.2 NVMe SSD power ready

※ LED 3 Green LED on indicates Gen-Z 1C PRSNT#

Specifications :

※ Support PCI Express Base Specification Rev 4.0

※ Compliant with PCIe M.2 Specification Revision 3.0, Version 1.2

※ Compliant with PCIe SFF-8639 Module Specification Rev 3.0

※ Compliant with SFF-TA-1002 Rev1.3

※ Compliant with SFF-TA-1006 Enterprise and Datacenter 1U Short SSD Form Factor Rev 1.4

※ Compliant with Gen-Z Scalable Connector Rev1.1

Supports the following form factor M.2(NGFF) SSD:

※ Type 2242-D2-B-M: 42mm(L) x 22mm(W)

※ Type 2260-D2-B-M: 60mm(L) x 22mm(W)

※ Type 2280-D2-B-M: 80mm(L) x 22mm(W)
